NX-WC100C

The NODEXON NX-WC100C is a high-performance wireless access point designed to provide fast, secure, and reliable Wi-Fi connectivity for modern business environments. It delivers stable performance, low latency, and efficient wireless coverage, making it ideal for offices, schools, hotels, and other high-density applications.

Key Features

  • ArrowEnterprise gateway with built-in routing & AC controller (CAPWAP-based)
  • ArrowManage 128APs (128-device capacity)
  • ArrowCloud-ready authentication gateway (supports SMS/user auth)
  • Arrow1x1 Gbps WAN port + 3x1 GbEWAN/LAN port + 1x1 Gbps LAN port xUSB port +1xConsole port
  • ArrowSupports multi-WAN configuration, link aggregation, load balancing, intelligent traffic control, online behavior management, VPN, and remote access control management
NX-WC100C

Specifications

Product type
Mounted/shell mounted
Serial port
1 Console serial port, RJ45 interface
USB
1 x USB3.0 port
Interface
WAN: 1 × 1GbE RJ45 port
WAN/LAN: 3 x 1GbE RJ45 ports
LAN: 1 x 1GbE RJ45 port
Button
1 Reset button
Power supply type
DC 12V
Power Interface
DC 2.0
Dimension
232.5mm x 152.5mm x 44.5mm (L x W x H)
Chassis Flixing Buckle
1U rack flixing ears
Work Environment
Operating temperature: -10°C to 50°C
Storage temperature: -20°C to 70°C
Humidity: 5% to 95% (no condensation)
