NX-5610-24F4F, 24-Port Multi-Gigabit Ethernet - L3 Pro Convergence Switch - 24 x 10G BASE-T, 4 x 10Gb SFP+, with 4 x 25Gb SFP28 Uplinks

Nodexon’s NX-5610-24F4F is a next-generation FS-developed switch. It is a L3 multi-gigabit hybrid optical/electrical switch. This switch comes with 24x 100M/1000M/2.5G/5G/10GBase-T and 4x 1/10G SFP+ with 4x 10G/25G SFP28 uplinks.

NX-5610-24F4F features wired and wireless convergence, it is compliable with PoE++ standards. With 10 GE data center server access It is an ideal high-speed wireless device access for campus network access/aggregation

Key Features

100M/1000M/2.5G/5G/10G-T, Up till 25G Uplinks
Capable of supporting QoS, NFPP, BGP, ACL, VRRP, QinQ et
Bears Power Wi-Fi 6 AP/IP Camera/Access Control/Printer
Good compatibility with 25G NVIDIA Mellanox NIC
Supports CLI/WEB/SNMP/RMON/Syslog/USB

Similar Models

NX-3875-28S4X

28-Port SFP L3 Managed Switch with SFP+

NX-5610-24F8G

24-Port GB SFP Layer 3 Switch with 4 10Gbe Ports

NX-3875-48G4X

48-Port Gigabit L3 Managed Switch with SFP+

NX-6510S-20X4S2Q

32×QSFP-DD 400GbE Ports & 2×SFP+10GbE Ports

Performance

802.1p, IP ToS, traffic filtering, SP, WRR
24x 100M/1000M/2.5G/5G/10G Base-T | 4x 1G/10G SFP+, 4x
10G/25G SFP28
Ports Base on Broadcom

Network Management

SNMP (Managed by Zabbix) support
RMON support
Log and configuration backup
Support Syslog
CLI, Web-based management, Telnet & SSH

Service Quality

Hardware CPU protection mechanism
DHCP snooping
IP-based Telnet device access control, source support
Secure Shell (SSH) and SNMPv3 Support

Energy Flow

Reduced energy consumption
Noise Variable-speed
Axial fans
Intelligently control the fan speed

Layer Switching

Line-rate IPv4/IPv6 dual-stack multi-layer.
RIP, OSPFv2, IS-ISv4, BGP4, static routing,
RIPng, OSPFv3, ISISv6, and BGP4+
IPv6 addressing, ICMPv6, Path MTU Discovery

Security Policies

Outstanding multilayer traffic categorization
Advance Security

Ports

24x 100M/1000M/2.5G/5G/10G

Switch Chip

BCM56170

Switching Capacity

760 Gbps

Forwarding Rate

565 Mpps

Power Budget

1GB

Airflow

Front-to-Back and Left-to-Back

Mounting Options

Desktop/Rackmount

PoE++

Support

Switch ASIC

Broadcom

Stacking

Support

Management

WEB, CLI, SNMP V1/V2/V3, RMON, Syslog, SFLOW, USB

Number of VLANs

4,000

Jumbo Frame

9,216

IPv4/IPv6 Routes

16,000

Dimensions (mm)

44.1x440x452.5mm

MTBF

>200,000 Hours
